TIG 210 AC / DC

  • TIG 210 AC / DC

TIG 210 AC/DC- portable TIG AC/DC inverter - also for aluminium

description

  • Portable TIG AC / DC inverter with 210 A from 230 V mains
  • Ideal device for all materials including aluminum and its alloys
  • Perfect for TIG and electrode welding in the workshop and on assembly
  • Through PFC no problems with fuse or with extension cords
  • Very clear and easy to use
  • All parameters immediately in direct access
  • With two - current function
  • With 9 memory slots
  • Can be switched on and off with HF
  • Remote controllable via optional accessories (foot remote control or potentiometer burner)

Direct selection and selection via the control panel

  • High Frequency Ignition: On or Off
  • Welding mode: 2-stroke or 4-stroke or 4-stroke with second current
  • Selection procedure: TIG or electrode
  • Gastest: On or Off
  • Programs: Save or call
  • Pulse function: On or Off

additionally only selectable for AC / DC systems:

  • Polarity change for electrode: AC or DC or DC +
  • AC waveform: Rectangle or sine or trapezoid or triangle

Adjustable parameters directly from the control panel:

  • via adjustment button forwards and backwards

for electrode welding:

  • Hot start electricity (for safe ignition)
  • Hot start time (for sure ignition)
  • Arc Force control (for arc stability)

for TIG welding:

  • Pre-gas
  • starting current
  • Current rise time
  • Welding current I1
  • Welding current I2 (second current)
  • Pulse frequency DC
  • Ratio of high current to low current
  • Stromababstiegszeit
  • End current
  • Post-gas

additionally only selectable for AC / DC systems:

  • AC frequency
  • AC balance

process

  • TIG
  • welding electrodes

sheet thicknesses

  • TIG from approx. 0.5 mm
  • Electrodes from approx. 2 mm

Base metals

  • unalloyed, low-alloyed materials
  • high alloyed materials
  • Stainless steels
  • CrNi steels ferritic / austenitic
  • Duplex steels
  • Nickel-based materials
  • Copper materials
  • Aluminum

Typical applications

  • Plant, container, machine, steel construction
  • Repair / Repair
  • Industrial plant and pipeline construction
  • Construction site and installation
